AquaCut is a high-precision CNC cutting machine designed for processing of a wide variety of materials including those that cannot be subject to thermal or mechanical stresses. Pure water or abrasive cutting can be applied to metal, stone, marble, armoured glass, ceramics, plastics, wood, corrugated cardboard, foamed material as well as sandwich materials. The machine can be equipped with a 5-axis waterjet rotator and also combined with plasma or drilling and tapping units.

Technical parameters

Working length 3000 - 18000 mm
Working width 1500 - 4000 mm
Max. number of tool stations 4
Max. thickness of material cut by plasma according to a plasma source
Max. thickness of material cut by waterjet 200
Bevel cutting yes (see accessories)
Pipe cutting inquire individually
Tapping M3 - M12
Positioning speed  max 56 m/min
Bidirectional repeatability 0.05 mm/m
Please note: The table above shows typical parameters. If you have different requirements, please contact us. All our solutions are tailor-made to customers' needs.

Inquiry formBrochure

Accessories

  • Plasma Rotator
  • Auto-calibration of Tool Geometry
  • Additional Beveling Process
  • Waterjet Straight Tool Station
  • Waterjet Rotator
  • Waterjet Multi-tool Station
  • Plasma Tool Station for Waterjet Machines
  • Sludge Removal Conveyor
